DHex is a software tool that is made to demonstrate the chemical design calculations of Double pipe (hairpin) Heat Exchangers. The software will do all the thermal calculations involved in the design and will generate a summary of all results.

Key features of Double Pipe Heat Exchanger Design (DHex):

• Step by step calculation
• Support S.I Units and English (U.S) Units of mesurement
• User database functions to allow user to add/delete components and  load to hot/cold side (Empty database!)
• Ability to import properties to Hot/Cold sides from Microsoft Excel
• Ability to calculate unknown Cold or Hot side temperatures
• Perform thermal analysis for bare tube double pipe (hairpin) heat exchangers.+Perform thermal analysis for finned tube double pipe (hairpin) heat exchangers
• Choose from Counter Current or Co-Current Flow arrangement
• Choose from Series arrangement or Series-Parallel arrangement
• The software will also tell you the location of Hot/Cold fluids within the heat exchanger (Inner Pipe or Outer Pipe)
• Calculate the Area, Flow area, Length, Log Mean Temperature Differance, Number of Hairpins,Unknown Flow rate
• Calculate the scale resistance (dirt factor), Equivalent Diameter
• Calculate Pipe/Annulus side Reynolds, Nusselt numbers & Prandtl Numbers
• Duty Calculation, Clean and Design Overall heat transfer coefficient calculations
• Pipe/Annulus velocities and Mass velocity calculations
• Number of Transfer Units and Thermal Capacity ratio calculation
• Pressure drop calculations & Entrance and Exit losses
• Export Results summary to Microsoft Excel

System Requirements:

• Windows operating system, 20MB Free space

Double Pipe Heat Exchanger Design (DHex) screenshot:
